Environmental
Operating Temperature Range
-40°C to 85°C
Operating RH Range
0 to 100 % RH, non-condensing
Ordering Information
Model Part Description
ChipCap-L ChipCap RH and Temperature Sensor, 0-1VDC Linear Output
ChipCap-R ChipCap RH and Temperature Sensor, 0.5- 4.5VDC
Ratiometric Output (5VDC Nominal)
ChipCap-D ChipCap RH and Temperature Sensor,
Digital Output
Packaging
Packaging
SOP-14, SMD
Soldering
IR Solder Re?ow, 260°C, 10 sec
Pin Connection
4 Pin; +V, Gnd, RHout, Tout
Absolute Maximum Ratings
-
-
Symbol
Vdd
Vio
Parameter
DC Supply Voltage
Voltage at all Analog and
Min.
-0.3
-0.3
Max.
6
Vdd + 0.3
Units
V
V
Notes
Digital I/O pins
Ta
Tstrg
Tj
Ambient Temperature
(operation)
Storage Temperature
Junction Temperature
-50
-40
-55
-55
150
85
150
160
°C
°C
°C
°C
ASIC
RH Sensor
Recommended Operation Conditions
Symbol
Vdd
Idd
Parameter
Analog DC Supply
Supply Current
Min.
3
Type
5
550
Max.
5.5
Units
V
A
Notes
25°C
Vss
Analog Ground
0.0
V
To
Cvdd
Ambient Temperature
External Capacitance
-40
100
27
220
85
470
°C
nF
between Vdd and Vss
C LD
Digital Output Load (only
100
pF
capacitive, no resistive)
C LA
Analog Output Load
5
nF
Capaictance
R LA
Analog Output Load
5
K
g
Resistance
www.gesensinginspection.com
920-426B
? 2008 General Electric Company. All Rights Reserved. Speci?cations are subject to change without notice. GE is a registered trademark of General Electric Company. Other company or product
names mentioned in this document may be trademarks or registered trademarks of their respective companies, which are not a liated with GE.
